Compaq 6530b - Notebook PC User Manual

3. Remove the three Phillips PM2.0×3.0 screws that secure the top cover to the computer.
4. Turn the computer right side up, with the front toward you.
5. Lift the rear edge of the top cover and swing it up and forward until it rests at an angle.
6. Release the ZIF connector to which the TouchPad board cable (1) is attached, and disconnect the
TouchPad board cable from the system board.
NOTE: The fingerprint reader board is available only on select models.
84 Chapter 4 Removal and replacement procedures

Compaq 6530b - Notebook PC Specifications

General

Processor	Intel Core 2 Duo
Graphics	Intel GMA 4500MHD
Operating System	Windows Vista Business
Battery Life	Up to 4 hours
Display	14.1-inch WXGA (1280x800)
Memory	Up to 4GB DDR2
Storage	120 GB to 250 GB 5400 rpm SATA
Battery	6-cell Lithium-Ion
Chipset	Mobile Intel GM45 Express
Optical Drive	DVD+/-RW SuperMulti with Double Layer
Networking	Integrated Intel Gigabit Network Connection (10/100/1000 NIC)
Wireless	802.11a/b/g/n
Audio	High Definition Audio, stereo speakers
Ports	VGA, RJ-45
Slots	ExpressCard/54
Processor Speed	2.53 GHz
