Compaq dc5750 - Microtower PC User Manual

3
Table 2 RAID Drives
NCQ Native Command Queuing.
Option ROM Third-party module that is loaded by the System BIOS which provides extended support for a
particular piece of hardware. The RAID Option ROM provides boot support for RAID volumes as
well as a user interface for managing and configuring the system’s RAID volumes.
PCI Peripheral Components Interface.
PCIe PCI express. A serial version of PCI.
PnP Plug and Play.
RAID Redundant Array of Independent Disks.
ROM Read Only Memory.
SATA Serial ATA.
Strip Set of data on a single hard drive in a RAID 0 volume.
Stripe Group of all strips going horizontally across all the hard drive members of a RAID 0 volume.
Mode Purpose Minimal HDD Required
RAID 0 Striped for Performance. 2
RAID 1 Mirrored for Protection. 2
RAID 0 + 1 Mirrored and Striped. 4*
* Not supported on HP Compaq dc5750 Business PCs.

Compaq dc5750 - Microtower PC Specifications

General

Network	Integrated Broadcom NetXtreme Gigabit Ethernet
Audio	Integrated High Definition audio
Form Factor	Microtower
Power Supply	300W
Processor	AMD Athlon 64 X2, AMD Athlon 64, or AMD Sempron
Memory	Up to 4 GB DDR2
Storage	SATA
Optical Drive	DVD-ROM or DVD+/-RW
Expansion Slots	1 PCIe x16
Ports	USB 2.0, VGA, serial, parallel, PS/2, audio in/out
Operating System	Windows XP Professional or Windows Vista
Weight	Approx. 18.5 lbs (8.4 kg)
