Compaq dc7700 - Convertible Minitower PC Utility Guide

●
Solve system configuration errors detected but not automatically fixed during the Power-On Self-
Test (POST).
●
Replicate the system setup by saving system configuration information on diskette and restoring
it on one or more computers.
●
Execute self-tests on a specified ATA hard drive (when supported by drive).
●
Enable or disable DriveLock security (when supported by drive).
Using Computer Setup (F10) Utilities
Computer Setup can be accessed only by turning the computer on or restarting the system. To access
the Computer Setup Utilities menu, complete the following steps:
1. Turn on or restart the computer.
2. As soon as the computer is turned on, press F10 when the monitor light turns green to enter
Computer Setup. Press Enter to bypass the title screen, if necessary.
NOTE: If you do not press F10 at the appropriate time, you must restart the computer and
again press F10 when the monitor light turns green to access the utility.
3. Select your language from the list and press Enter.
4. A choice of five headings appears in the Computer Setup Utilities menu: File, Storage, Security,
Power and Advanced.
5. Use the arrow (left and right) keys to select the appropriate heading. Use the arrow (up and down)
keys to select the option you want, then press Enter. To return to the Computer Setup Utilities
menu, press Esc.
6. To apply and save changes, select File > Save Changes and Exit.
●
If you have made changes that you do not want applied, select Ignore Changes and Exit.
●
To reset to factory settings or previously saved default settings (some models), select Apply
Defaults and Exit. This option will restore the original factory system defaults.
CAUTION: Do NOT turn the computer power OFF while the ROM is saving the Computer Setup
(F10) changes because the CMOS could become corrupted. It is safe to turn off the computer
only after exiting the F10 Setup screen.
Table 1 Computer Setup (F10) Utility
Heading Table
File Table 2 Computer Setup—File on page 3
Storage Table 3 Computer Setup—Storage on page 4
Security Table 4 Computer Setup—Security on page 7
Power Table 5 Computer Setup—Power on page 9
Advanced Table 6 Computer Setup—Advanced (for advanced users)
on page 10
2 Computer Setup (F10) Utility ENWW

Compaq dc7700 - Convertible Minitower PC Specifications

General

Chipset	Intel Q965 Express
Memory Slots	4 DIMM slots
Form Factor	Convertible Minitower
Processor	Intel Core 2 Duo, Pentium D
Memory	Up to 8 GB DDR2 SDRAM
Storage	80GB, 160GB, 250GB, 500GB HDD
Graphics	Intel GMA 3000
Optical Drive	DVD-ROM, DVD+/-RW
Audio	Integrated High Definition Audio
Network	Integrated Intel Gigabit Network Connection
Expansion Slots	1 PCIe x16, 1 PCI Express x1, 2 PCI
Ports	USB 2.0, Serial, Parallel, PS/2, Audio
SATA Ports	4
Operating System	Windows XP Professional, Windows Vista Business
Power Supply	365W
