Quick Setup
Connecting Devices
Connect the monitor, mouse, and keyboard cables to the personal
computer. If you use a network, connect the network cable to the
Ethernet RJ-45 Connector. Connectors are color-coded for easy setup.
The connectors are shaped to go in one way only. Typical connectors
are shown below:
Å
WARNING: To reduce the risk of electrical shock, fire, or damage to
the equipment, do not plug telecommunications/telephone connections
into the network interface controller (NIC) connectors.
Ä
CAUTION: Do not add additional, optional hardware devices to your
personal computer until the operating system is successfully installed.
Doing so may cause errors and may prevent the operating system from
installing properly.
4 x USB 2.0
LAN
monitor
2 x USB 2.0
USB ↔ serial
USB ↔ printer
