Compaq Evo N800c Series

Removal and Replacement Procedures
Maintenance and Service Guide 5–7
6. Remove the hard drive by following these steps:
a. Turn the notebook bottom side up with the left side
facing forward.
b. Remove the PM3.0 × 4.0 hard drive retention screw
1
(Figure 5-5).
c. Slide the hard drive forward 2 to unseat the hard drive
connector from the system board.
d. Remove the hard drive.
Figure 5-5. Removing the Hard Drive
