SPECIFICATIONS
System Specifications (continued)
General system specifications
Video memory
System interrupts
System I-O
System memory
System DMA
System I/O
I/O Address (Hex) System Function (Shipping Configuration)
0000h-000Fh Direct memory access controller
0010h-001Fh Motherboard resources
0020h-003Fh Programmable interrupt controller
0040h-0043h System timer
004Eh-004Fh Motherboard resources
0050h-0052h Motherboard resources
0060h-0060h Motherboard resources
0061h-0061h System speaker
0064h-0064h Motherboard resources
0070h-0071h System CMOS/real time clock
0072h-0077h Motherboard resources
0080h-008Fh Direct memory access controller
0090h-009Fh Motherboard resources
00A0h-00BFh Programmable interrupt controller
00C0h-00DFh Direct memory access controller
00F0h-00FFh Numeric data processor
0170h-0177h Secondary IDE controller (dual fifo)
0170h-0177h Intel(r) 82801AA Ultra ATA Controller
01F0h-01F7h Intel(r) 82801AA Ultra ATA Controller
01F0h-01F7h Primary IDE controller (dual fifo)
0376h-0376h Intel(r) 82801AA Ultra ATA Controller
0376h-0376h Secondary IDE controller (dual fifo)
0390h-0397h Motherboard resources
03B0h-03BBh Intel(R) 810e Chipset Graphics Driver (DC133 FSB133)
4.11.01.
03C0h-03DFh Intel(R) 810e Chipset Graphics Driver (DC133 FSB133)
4.11.01.
03F0h-03F5h Standard Floppy Disk Controller
03F6h-03F6h Primary IDE controller (dual fifo)
03F6h-03F6h Intel(r) 82801AA Ultra ATA Controller
0400h-047Fh Motherboard resources
04D0h-04D1h Motherboard resources
0CF8h-0CFFh PCI bus
2000h-20FFh SoundMAX Integrated Digital Audio
2400h-243Fh SoundMAX Integrated Digital Audio
2460h-246Fh Intel(r) 82801AA Ultra ATA Controller
2460h-2467h Primary IDE controller (dual fifo)
2468h-246Fh Secondary IDE controller (dual fifo)
EE00h-EE7Fh Motherboard resources
EE80h-EEBFh Motherboard resources
EEC0h-EEDFh Intel(r) 82801AA USB Universal Host Controller
EEE0h-EEEFh Intel(r) 82801AA SMBus Controller
