Maintenance and Service Guide
Compaq Presario EZ2000 Series Computers
Product Description Troubleshooting Illustrated Parts Catalog
Home Removal & Replacement Jumper & Switch Information Specifications
REMOVAL & REPLACEMENT
Removing the I/O Board, continued
Removal
7
Remove (1) two screws from the
front of the I/O Bracket and (2)
push back on the I/O Bracket to
remove from the chassis.
Replacement
To replace the I/O board,
reverse this procedure.
