REMOVAL & REPLACEMENT
System Board Components
Removing the Heatsink/Processor Assembly, continued
Removal
5
Twist the heatsink/processor
(clockwise) to remove the
processor from the heatsink.
Replacement
To replace the heatsink/processor,
reverse the previous procedure.
Return to System Board and Components
