Maintenance and Service Guide
Compaq Presario EZ2000 Series Computers
Product Description Troubleshooting Illustrated Parts Catalog
Home Removal & Replacement Jumper & Switch Information Specifications
REMOVAL & REPLACEMENT
System Board Components
Removing the Heatsink/Processor Assembly
Removal
1
Perform preparation procedures.
2
Remove the Left Easy Access
panel.
3
Remove the drive cage.
4
Lift up the (1) ZIF socket handle
and (2) remove the heatsink with
processor attached.
Next Step
