Maintenance and Service Guide
Compaq Presario EZ2000 Series Computers
Product Description Troubleshooting Illustrated Parts Catalog
Home Removal & Replacement Jumper & Switch Information Specifications
REMOVAL & REPLACEMENT
Removing the System Board
Removal
1
Perform preparation procedures.
2
Remove the Left Easy Access panel.
3
Remove the Top Access cover.
4
Remove the drive cage.
5
Remove six screws securing the system
broad to the chassis and remove from
the chassis.
To replace the system board reverse the
previous procedure.
System board components index page
