PRODUCT DESCRIPTION
Rear CPU Connectors
1
USB Port (2)
2
Microphone In
3
Audio Line Out
4
1394 Connector
5
SVGA Monitor Port
6
*Network Interface Connector
7
Modem (line)
8
Audio Line In
9
Voltage Select Switch
10
AC Power Connector
11
Modem (phone)
*
IMPORTANT: Modem configuration
may vary depending on the model
selected.
