To replace the keyboard, reverse the steps in the previous illustrations.
Chapter 5.6 CHASSIS
1. Remove the hinge covers and keyboard, section 5.5.
2. Remove the battery pack, section 5.4.
3. Lower the display.
4. Use the Torx T-15 screwdriver to remove the rear panel screws. The rear
panel will contain two long screws in the middle and four short screws in
the corners.
To Next Page
