Technical Specifications
36 English
Technical Specifications
Liquid Crystal
Display (LCD)
Display Size 17 in. (43 cm) diagonal and
viewable image
Type TFT liquid crystal display
Input Signal Video 0.7 V (0,7) p-p analog RGB
Synchronization Separated H/V (TTL level)
Interface Input Connector 15-pin D-SUB (Analog)
DVI-D (Digital)
Scanning
Frequency
Horizontal 30–80 kHz
Vertical 56–75 Hz
Resolution
(H x V)
Maximum 1280 x 1024 @ 75 Hz
Recommended 1280 x 1024 @ 60 Hz
Power Source AC/DC Adapter Input Rating:
100–240 V~ auto-range,
2 A max.
Output Rating:
12 V , 4.16 A (4,16 A)
Frequency: 50-60 Hz
Input Voltage: 12 V
Input Current: 3.5 A (3,5 A)
Power
Consumption
Base Unit Operating mode: 45 W max.
Sleep mode: 2.3 W (2,3 W)
Operating
Environment
Temperature 10° C to 35° C
Humidity 20% RH through 80% RH
(without condensation)
Storage
Environment
Temperature –10° C to 60° C
Humidity 8% RH through 85% RH
(without condensation)
Dimensions
(H x W x D)
With stand 418 x 38 x 370 mm
(16.5 x 1.5 x 14.6 in)
Weight With stand 6.4kg (6,4kg) 14.1lb
Tilt Stand Tilt Angle: Down 5, up 25 degrees
Security Lock Monitor cabinet is provided with a slot allowing the use of
Kensington
TM
lock device
