II.2 Installation sequence
Installation of the mechanism: non-motor side
• Install the non-motor flange
inside the pool with bolts
M8x30
• Put a seal between flange and
pool wall
• These bolts are screwed into
the counter flange
• Put a seal between flange and
pool wall
4
16
