VII.6 : Remote control
1
4
2
3
Antenna with coax cable11
Channel B of the remote control10
Channel A of the remote control9
Antenna8
DELETE button7
MEMO button6
Connector to plug the receiver on the control board5
Plastic plugs to connect the relay card to the control box housing4
Relay 4: Use this relay to switch the pool lights3
Data cable to connect the relay card to the control board2
Relay card with 4x 16A relays1
Part descriptionNr
Receiver
Transmitter
5
6 7 8
9
10
11
core
mantle
