II.1 Summary of the different parts of the mechanism
AT-001959Washer19
AT-002326Bolt M6x12 to fix the straps to the shaft18
AT-00252445°PVC elbow Ø 32mm17
AT-002598Counter flange16
AT-002497PVC socket15
AT-002057PVC tube Ø 32mm PVC PN1014
AT-002047Shaft SS AISI 316L Ø 30 mm – L=170mm12
AT-002009Wall duct flange11
AT-002034Strap to connect the slats to the roller shaft10
AT-002010Motor flange9
AT-002017Drive block for tube Ø 139,7x2 mm8
AT-002018POM bearing for tube Ø 139,7x2 mm (drive side)7
AT-002581In-roller motor 24Vdc6
AT-002066Seal in PUR5
AT-002054Non-motor flange4
AT-002052Ring to lock/secure the roller shaft3
AT-002019POM bearing for tube Ø 139,7x2 mm 2
AT-001978SS AISI 316L tube Ø 139,7x2 mm – L=4m1
Part NumberPart NameDrawing Number
