• Install the motor flange at the
inside of the pool with bolts
M8x35
• Put a seal between flange and
pool wall
• Screw the bolts M8x35 into the
wall duct flange
• Put a seal between flange and
pool wall
II.2 Installation sequence
Installation of the mechanism: motor side
5
11
9
