English Compex 8 Port Dual Speed Fast Ethernet
Switch (PS2208B)
3
♦ Forwarding Method: Store-and-Forward.
♦ Number of MAC
Addresses:
8K MAC Addresses.
♦ Dynamic Addresses
Learning/Filtering:
Yes.
♦ Power Supply: External 7.5VDC, 1.5A
♦ Environment
Requirements:
Temperature: Operating: 0°C to 40°C
Storage: -5°C to 60°C
Humidity: Operating: 10% to 90%
(non-condensing)
♦ Physical Dimensions: 151 x 92x 25mm (L x W x H)
♦ Weight: About 0.20 kg
♦ Safety: UL, CSA, TUV/GS.
Ø
Installation of PS2208B
PS2208B can be installed on a flat surface (desktop) or mounted on a wall. Follow
the steps below for proper installation.
Desktop installation:
1. Unpack the switch.
2. Choose a location near the devices to be connected and close to an electrical outlet.
3. Set the switch on a desktop or any other clean, smooth, level and sturdy surface.
Make sure there is enough clearance around the unit to allow attachment of network
cables, power adapter and allow air circulation.
4. Connect the power adapter to the switch. The POWER LED and PORT LED for
each connected port should light up.
5. The switch is ready to operate.
Wall installation:
1. Measure the distance between the mounting holes at the bottom of the switch and
mark the wall to match the location of the mounting holes on the switch.
2. Drill pilot holes at the two marked locations.
3. Fix two 5/16-inch diameters flat-head mounting screws into the wall, with the heads
of the screws protruded 1/8 inch out from the wall.
4. Carefully set the switch over the screws in the wall; then slide the hub down onto the
screws, pressing it slight to the wall.
5. Connect the power adapter to the switch. The POWER LED and PORT LED for
each connected port should light up.
6. The switch is ready to operate.
