Comprehensive CHE-1 - Application Example

6. Application Example
IR OUT DC 5V
HDMI OUTEDID
HDMI IN
CAT
IR IN DC 5VCAT
HDMI OUT
DVD or Blu-ray Player
UHDTV
UHDTV
IR Receiver
LAN
LAN
IR Blaster
Transmitter
Receiver
The terms HDMI and HDMI High-Definition Multimedia interface, and the HDMI Logo are trademarks or registered trademarks
of HDMI Licensing LLC in the United States and other countries.
Power Supply
CAT5E/6 cable
7/7
Power Supply
