HaYetsira St. 17, Yokneam, Israel
Tel:
+972-48-290-168
Fax:
+972-48-325-251
www.airtop-pc.com
www.airtop-pc.com Page 8 of 25 Airtop owner’s manual
Discrete Graphics
GPU
NVIDIA GeForce GTX 950 Graphics Card (refer to specific model)
Display I/F 1
DisplayPort 1.2 up to 4096×2160 @ 60 Hz
Display I/F 2
DisplayPort 1.2 up to 4096×2160 @ 60 Hz
Display I/F 3
DisplayPort 1.2 up to 4096×2160 @ 60 Hz
Display I/F 4
HDMI 2.0 / DisplayPort 1.2 up to 4096×2160 @ 60 Hz (refer to specific model)
Audio
Codec
Realtek ALC886 HD audio codec
Audio Output
Digital 5.1-ch TOSLINK output
Analog 2-ch stereo output
3.5mm jack
Audio Input
Analog microphone input
3.5mm jack
Networking
LAN
2x GbE LAN ports (by option additional 4x GbE)
LAN1: Intel I218 GbE PHY (MAC integrated into the chipset) (RJ-45)
LAN2: Intel I210 GbE controller (RJ-45)
Wireless
WLAN
WLAN 802.11ac (2.4/5GHz dual band Intel 7260HMW)
Bluetooth
Bluetooth 4.0
Cellular
2x micro SIM slot (6 pins)
Connectivity
USB3
4x USB 3.0 (back)
USB2
2x USB 2.0 (back)
4x USB 2.0 (front)
Serial
3x Serial communication ports
COM0: Full RS232 via mini serial connector
COM1: 2-wire RS232 via mini serial connector
COM3: 2-wire RS232 via mini serial connector
