PRT9065 and PRT9080 models - Base Configuration – 4/6 pin
FRONT1 PUSH TRACTOR
Fanfold Width: 76 to 432 mm (3 to 17 inches)
Copies: 1 original + 7 copies Max. thickness 0,635 mm (0.025 inches)
PRT9065 and PRT9080 models – Options – 4/6 pin
FRONT2 PUSH TRACTOR Option
Fanfold Width: 76 to 432 mm (3 to 17 inches)
Copies: 1 original + 7 copies Max. thickness 0,635 mm (0.025 inches)
Physical and Electrical Characteristics
Interfaces
Parallel Centronics Compatible Bi-directional (IEEE-1284) nibble and byte modes - 36 pin
Amphenol connector, 7/8 data bits
Receive Buffer: max. 128 Kbytes
Serial RS-232/C - dB 9 connector
Baud Rate: 300 to 115200 bps, 7/8 data bits, DTR & XonXoff flow
Receive Buffer: max. 128 Kbytes
USB Type B USB 2.0 Compatible Bi-directional - 4 pin connector, 12Mbit/s
LAN 10BASE-T – 100BASE-TX – RJ45 8 pin connector
Automatic interface switching
Reliability
MTBF Mean Time between failure: 20,000 hours at 25% DC
