Setting the Parallel Interface Parameters
Interface Type
INTERFACE PARALL INTERFACE
↑
↑
PARALL INTERFACE
→
1284 BIDIR. I/F
→ or ←
↓
CX. PARALLEL I/F
→ or ←
SERIAL INTERFACE
↓
SELECT-IN HOST
1284 BIDIR. I/F
Bidirectional IEEE 1284 parallel interface.
CX. PARALLEL I/F
Centronics type parallel interface (mono-directional).
Setting the Select-In Signal
1284 BIDIR . I/F
↑
SELECT-IN HOST
→ or ←
SELECT-IN ON
→ or ←
↓
DATA BITS 8
SELECT-IN HOST
The printer checks the SELECT-IN signal coming from the host.
SELECT-IN ON
The SELECT-IN signal of the parallel interface is ignored and treated always
as ON.
