CompuSTAR Firstech CM800-S - Option Menu Descriptions; Options 1-01 to 1-11 Descriptions

14
3-02
Aux 1 Output
0.5 Second
Latched
20 Seconds
Program
3-03
Aux 2 Output
0.5 Second
Latched
60 Seconds
Program
3-04
Aux 1 Output Control
By Remote
Arm
Disarm
Ignition Off
3-05
Aux 2 Output Control
By Remote
Arm
Disarm
Panic
3-06
Horn Mute Control on
Remote
Disabled
Enabled
3-07
Sliding Door(Aux1, Aux2)
Control for iDatalink
Modules
Off
Unlock, Factory
Disarm,
and Sliding Door
Control
Factory Disarm and
Sliding Door Control
Only
3-08
CN 2 PIN 4
Status
Ignition
Aux1
Aux2
3-09
CN 2 PIN 5
Rearm
Ignition
Aux1
Aux2
3-10
CN 2 PIN 6
Disarm
Ignition
Aux1
Aux2
3-11
CN 2 PIN 7
Horn
Ignition
Aux1
Aux2
Special Option Group
Feature
Setting Value (Seconds)
1
Aux 1 output
1- 99 seconds
2
Aux 2 output
1-99 seconds
IMPORTANT: System must be unlocked before you can set options with the OP500 or remotes.
*Once programmed, this feature requires activation from the remote. Please refer to the
remote user manual or the option description below.
Option Menu Descriptions
1-01 Unlock Before, Lock After Starting - If enabled, this option will unlock the doors before remote
starting, start the vehicle, then lock the doors after the vehicle starts. It will then lock the doors
again if the remote start run time expires and the vehicle shuts down. The third option locks the
doors upon remote start shut down only. The fourth option turns on lock after remote start
shutdown only. This feature is for vehicles that have factory alarms that need to be disarmed
before remote starting such as Toyota and Lexus.
1-02 Lock / Unlock Pulse Duration – This option changes the length of the lock and unlock ground
pulses on the blue and blue/black wires on CN3. The default setting is for 0.8 seconds. Optional
setting 2 changes the duration to a 2.5 second pulse. The third setting changes the duration to a
short 0.125 second pulse setting. The fourth setting changes the duration to a 3.5 second pulse.
1-03 Double Pulse Locks – This option changes the behavior of both the lock and/or unlock wires.
This feature cannot be used with Option 1-04.
