PRODUCT DESCRIPTION
1 Refrigerator lighting
2 Butter and cheese compartment
3 Small food compartement
4 Glass shelves
5 Fruit and vegetable drawer
6 Bottle containers
7 Variable drawer
with adjustable temperature
8 Upper freezer drawer
9 Lower freezer drawer
CONTROL PANEL DESCRIPTION
1 Cooling icon
2 Radar icon
3 Freezing icon
4 OFF icon
5 Unlock/lock of control panel icon
6 Temperature display
7 Super Cool icon
8 Vacation icon
9 Super Freeze icon
10 Sensor button – refrigerator temperature setting
11 Sensor button – freeze temperature setting
12 Sensor button to set the Super Cool function
13 Sensor button to set the Super Freeze function
14 Sensor button to set the Vacation function
15 Sensor button to lock/unlock control panel
