19
Table 9 — DIP Switch Settings
Display Number
Security
Lockout
Reserved
RS-485
selected
Serial
Enabled
BAR
PSI
Reserved
Display Number
Security
Lockout
Reserved
RS-485
selected
Serial
Enabled
BAR
PSI
Reserved
SW3 SW1 SW3 SW1
DIP Switch Position DIP Switch Position
4 3 2 1 12 11 10 4 3 2 1 12 11 10
0 OFF OFF OFF OFF OFF OFF OFF 64 ON OFF OFF OFF OFF OFF OFF
1 OFF OFF OFF OFF OFF OFF ON 65 ON OFF OFF OFF OFF OFF ON
2 OFF OFF OFF OFF OFF ON OFF 66 ON OFF OFF OFF OFF ON OFF
3 OFF OFF OFF OFF OFF ON ON 67 ON OFF OFF OFF OFF ON ON
4 OFF OFF OFF OFF ON OFF OFF 68 ON OFF OFF OFF ON OFF OFF
5 OFF OFF OFF OFF ON OFF ON 69 ON OFF OFF OFF ON OFF ON
8 OFF OFF OFF ON OFF OFF OFF 72 ON OFF OFF ON OFF OFF OFF
9 OFF OFF OFF ON OFF OFF ON 73 ON OFF OFF ON OFF OFF ON
10 OFF OFF OFF ON OFF ON OFF 74 ON OFF OFF ON OFF ON OFF
11 OFF OFF OFF ON OFF ON ON 75 ON OFF OFF ON OFF ON ON
12 OFF OFF OFF ON ON OFF OFF 76 ON OFF OFF ON ON OFF OFF
13 OFF OFF OFF ON ON OFF ON 77 ON OFF OFF ON ON OFF ON
24 OFF OFF ON ON OFF OFF OFF 88 ON OFF ON ON OFF OFF OFF
25 OFF OFF ON ON OFF OFF ON 89 ON OFF ON ON OFF OFF ON
26 OFF OFF ON ON OFF ON OFF 90 ON OFF ON ON OFF ON OFF
27 OFF OFF ON ON OFF ON ON 91 ON OFF ON ON OFF ON ON
28 OFF OFF ON ON ON OFF OFF 92 ON OFF ON ON ON OFF OFF
29 OFF OFF ON ON ON OFF ON 93 ON OFF ON ON ON OFF ON
32 OFF ON OFF OFF OFF OFF OFF 96 ON ON OFF OFF OFF OFF OFF
33 OFF ON OFF OFF OFF OFF ON 97 ON ON OFF OFF OFF OFF ON
34 OFF ON OFF OFF OFF ON OFF 98 ON ON OFF OFF OFF ON OFF
35 OFF ON OFF OFF OFF ON ON 99 ON ON OFF OFF OFF ON ON
36 OFF ON OFF OFF ON OFF OFF 100 ON ON OFF OFF ON OFF OFF
37 OFF ON OFF OFF ON OFF ON 101 ON ON OFF OFF ON OFF ON
40 OFF ON OFF ON OFF OFF OFF 104 ON ON OFF ON OFF OFF OFF
41 OFF ON OFF ON OFF OFF ON 105 ON ON OFF ON OFF OFF ON
42 OFF ON OFF ON OFF ON OFF 106 ON ON OFF ON OFF ON OFF
43 OFF ON OFF ON OFF ON ON 107 ON ON OFF ON OFF ON ON
44 OFF ON OFF ON ON OFF OFF 108 ON ON OFF ON ON OFF OFF
45 OFF ON OFF ON ON OFF ON 109 ON ON OFF ON ON OFF ON
56 OFF ON ON ON OFF OFF OFF 112 ON ON ON ON OFF OFF OFF
57 OFF ON ON ON OFF OFF ON 113 ON ON ON ON OFF OFF ON
58 OFF ON ON ON OFF ON OFF 114 ON ON ON ON OFF ON OFF
59 OFF ON ON ON OFF ON ON 115 ON ON ON ON OFF ON ON
60 OFF ON ON ON ON OFF OFF 124 ON ON ON ON ON OFF OFF
61 OFF ON ON ON ON OFF ON 125 ON ON ON ON ON OFF ON
