INSTALLATION
Installation
Selection of installation equipment
- Cut out the work surface according to the sizes shown in the drawing.
- For the purpose of installation and use, a minimum of 50mm space shall be
preserved around the hole.
- Be sure the thickness of the work surface is at least 30mm. please select
heat-resistant work surface material to avoid larger deformation caused by the heat
radiation from the hotplate. As shown below:
·Put a towel or cloth on the work surface. Place the hob face down on the protected surface.
·Apply the strip seal, supplied with the hop, which is for sealing it onto the work surface.
·Do not use silicone. Apply the seal to the edge of the bottom of the hob, leaving about 3mm
from the edge of glass. Apply the seal all around the circumference.
·Cut any excess and bring the two ends of the seal together so they match.
