5
Getting Started
Back View
VGA
PC
AUDIO
RF USB
HDMI2 HDMI3
(ARC)
HDMI1
L R
AUDIO IN
R L
AUDIO OUT
Y/VIDEO Pb Pr
Headphone OPTICAL
10. USB Port
Connecting for USB device.
6. HDMI Input Jack
Connecting of HDMI signal.
7. VGA Input
Connecting to the video output jack a personal computer.
8. PC Audio Input Jack
Connected to the audio output jack on a personal computer.
5. YPbPr Input Jack
Connecting for component signal input in YPbPr mode.
Note: Y and VIDEO interface is shared.
9. Antenna Input Jack
Connecting to external antenna to receive the TV.
2. Headphone Jack
3. Optical Output Jack
4. Audio Input Jack
Note: YPbPr and AV audio is shared.
1. Audio Output Jack
CT-2270
CT-2860/CT-3270
L R
AUDIO IN
Y/VIDEO Pb Pr
HEAD
PHONE
OPTICAL
VGA
PC
AUDIO
R L
AUDIO OUT
HDMI RF USB
