Contractor CAB-110P - Page 37

ENGLISH
CONTRACOR
®
CAB-110P/CAB-135P Art. 15205/15206
37
7.3.Light assembly
1
2
3
4
Picture 18. Fluorescent tube replacement
Pos. No Order code Description Amount
1 16122 Tube uorescent, 30 W 2
2 16121 Light assembly, 2x30 Watt 1
3 16123 Lamp reector 1
4 16049 Gasket 3х15, Disposable window / Electrical enclosure, 1m 4 m
7.4. Pneumatic circuit diagram
Picture 19. Pneumatic
circuit diagram
CAB-110P/ 135P
