• New construction, Control4 recommmends these options:
• Install a common wire.
• Use a Remote Temperature Sensor in the wall where the Thermostat is located. Run a wire to
the furnace, and then install the Thermostat next to the furnace.
• Retrofits, the best solution is to install the Thermostat using an existing common wire. If the box
does not have a common wire, you can:
• Run a wire from the furnace to the Thermostat location.
• Use Power Stealing (see Step 14 in “Installation Instructions”).
• Install a Remote Temperature Sensor in the wall where the Thermostat is located. Run a wire to
the furnace, and install the Thermostat next to the furnace. See “Remote Temperature
Sensor.”
• Use a separate 24VAC transformer to power the Thermostat.
Supported System Types
This table lists the items that the Thermostat replaces.
Description CCZ-T1-W
Heat pump (no aux. or emergency heat) Yes
Heat pump (with aux. or emergency heat) Yes
Standard heating and cooling system Yes
Two-stage heat and two-stage cooled Yes
Standard heat-only systems Yes
Millivolt heat-only systems - floor or wall furnaces Yes
Standard central air conditioning Yes
Gas or oil heat Yes
Electric furnace Yes
Hydronic (hot water) - zone heat - 2 wires Yes
Hydronic (hot water) - zone heat - 3 wires No
5
