clignoté 12 fois par seconde. Après la période
de 10 secondes de clignotement, le circuit de
sur-courant sera réactivé. Si la condition de
surintensité reste donc la même, la séquence
se répète.
For more information, refer to the Products or
Documentation pages at www.control4.com.
Requirements and Specifications
NOTES:
(1) We recommend using Ethernet rather than
WiFi for the best network connectivity.
(2) The Ethernet or WiFi network should
be installed prior to starting the HC-250
installation.
(3) The HC-250 is only compatible with PoE
injectors that have DC ground isolated from
AC ground. The easiest way to determine if
this is the case is to use PoE injectors that only
have a two-prong AC power cord. You can find
additional PoE information on the Control4
Knowledgebase.
(4) Ferrite clamp installation. When installing
a Control4® HC-250 Controller, also install the
enclosed ferrite clamps as described in this
document.
Ethernet cable. Install two (2) ferrite clamps
on the Ethernet cable no farther than 6 inches
from the HC-250 Ethernet jack.
Video cable. Install two (2) ferrite clamps on
each end of the HDMI or Component video
cable no farther than 6 inches from the HC-
250 and the TV.
HC-250 Controller
Installation Guide
The software required to configure this device is
Composer Pro. See the Composer Pro User Guide for
details.
HC-250 Specifications
Model Number
C4-HC250-BL
Network
Ethernet—required
WiFi (only supported
when the unit is used in a
single-Controller system or as a
Secondary Controller)
Media Recognition
Online CD/DVD/Blu-ray
recognition and media information
service. Supports MP3, AAC, FLAC.
Video
HDMI 1.4 output; Component
Video output; SD 480I; HD 720p,
50-60Hz.
Audio Playback Formats
MP3: 32kbps to 320kbps, CBR,
VBR, AAC, and FLAC
Display
LED indicators
Power Requirements
100-240 VAC, 60/50 Hz, 0.25 A
PoE requirement: 13W
Power Consumption
Max: 44W, 150 BTUs/hour.
Idle: 24W, 82 BTUs/hour
Operating Temperature
32˚ - 104˚ F (0˚ - 40˚ C)
Storage Temperature
-4˚ - 149˚ F (-20˚ - 65˚ C)
IR Out
5V 27 mA max/output
IR Capture
0-60 KHz
Contact (1)
DC - 36V maximum operation (low
voltage)
Maximum output current for 12V
rail: 125mA
Relay (1)
AC - 36V, 2A
DC - 24V, 2A
maximum operation (low voltage)
Dimensions (H x W x D)
1.23” (31.19 mm) x 8.59” (218.13 mm)
x 4.92” (125.01 mm)
Weight
1.3 lbs/0.589 kg
Shipping Weight
2.7 lbs/1.224 kg
Additional Resources
The following resources are available for more
support.
• Control4 Knowledgebase and Forums
• Control4 Technical Support
• Control4 website: http://www.control4.com
• Composer documentation in online help or PDF
format available on the Dealer portal
