Control 4 Wireless thermostat User Manual

23
Low Battery
When battery is low, a battery icon indicating a low battery power appears right of the temperature on Wireless
Thermostat LCD screen.
Battery Replacement
To replace battery:
1 Detach front faceplate by releasing the latch at the bottom of the Thermostat and sliding the faceplate up
and off.
2 Remove old battery. See “Battery Replacement Safety Rules” on page 3.
3 Install new battery by ensuring that you insert the battery into the thermostat according to the polarity labels,
POS (+) and NEG (-), on the thermostat circuit board.
4 Replace the Thermostat faceplate.
1. Align the faceplate with the
rear plate and push the
straight pins to the back of
the thermostat.
2. With the faceplate slightly
above the rear plate, slide
the top edge of the faceplate
onto the rear plate, engaging
the plastic hooks with the
corresponding holes.
3. Press firmly on the bottom
center edge of the faceplace
to snap and lock the bottom
connector in place.
