CONTROL PANEL SPECIFIC ALARMS AND SHUT DOWNS
The panel has its own engine safety alarms and shut downs that can be enabled. These alarms
and shut downs are managed by the control panel independent from the engine ECU. The
available options are listed below and can be accessed via the Engine Safety Configuration menu.
The panel is shipped from the factory with these parameters disabled. They must be enabled to
activate.
Heading
Default
Range
Units
Sender Check Bypass
0:10
0:05 – 1:00
Min:Sec
Fuel Level Check
Run
Off / Always / Run
Low Fuel Pre Alarm
20
0 - 100
%
Low Fuel Alarm
1
0 - 100
%
Fuel Alarm Delay
0:05
0:01 – 1:40
Sec
Oil Pressure Check
Off
Off / Always / Run
Low Oil Press Pre Alarm
15
0 - 100
PSI
Low Oil Press Alarm
10
0 - 100
PSI
Oil Press Alarm Delay
5
0:01 – 1:40
Sec
Temperature Check
Off
Off / Always / Run
Low Temp Pre Alarm
0
0 - 300
Deg F
Low Temp Alarm
0
0 - 300
Deg F
High Temp Pre Alarm
220
150 - 300
Deg F
High Temp Alarm
230
150 - 300
Deg F
Temp Alarm Delay
0:05
0:01 – 1:40
Min:Sec
Battery Volts Check
Off
Off / Always / Run
Lo Battery Pre Alarm
12.0
0.0 – 40.0
Volts
Hi Battery Pre Alarm
15.0
0.0 – 40.0
Volts
Over Speed Check
Off
Off / Always / Run
Over Speed Alarm
3000
650 - 5000
RPM
Over Speed Alarm Delay
0:05
0:01 – 1:40
Min:Sec
1) Off / Always / Run – Describes when the parameter will be monitored for alarm conditions. Run
refers to when the engine is running. Off disables the alarm conditions. Always enables the
alarm constantly regardless of engine state.
2) Alarm Delay – The time period, after Sender Check Bypass, that the parameter must be on the
alarm condition before the alarm becomes latched.
