CONTROL PANEL SETTINGS
Prior to starting the engine, select the proper throttle control mode and parameters required
for application.
Start/Stop Engine Engine Throttle Backup Floats
Method ON OFF Type Throttle Operation Available
Manual Key to Start Key to Off Vernier Manual UP/DOWN between selected min and max speeds -
Manual Key to Start Key to Off Multistate Select up to four separate operating speeds -
Start/Stop Engine Engine Throttle Backup Floats
Method ON OFF Type Throttle Operation Available
Floats Floats Close Floats Open Single Speed Single operating speed with warm up and cool down -
Floats Floats Close Floats Open Linear Engine speed adjusted between selected min and max speeds -
Floats Floats Close Floats Open Target Engine speed adjusted to maintain selected level or pressure -
Pressure On Pressure Off Pressure Single Speed Single operating speed with warm up and cool down Yes
Pressure On Pressure Off Pressure Linear Engine speed adjusted between selected min and max speeds Yes
Pressure On Pressure Off Pressure Target Engine speed adjusted to maintain selected pressure level Yes
Level On Level Off Level Single Speed Single operating speed with warm up and cool down Yes
Level On Level Off Level Linear Engine speed adjusted between selected min and max speeds Yes
Level On Level Off Level Target Engine speed adjusted to maintain selected level Yes
Auto Operation Options
Manual Operation Options
MANUAL OPERATION
1) Engine Start/Stop – Turn key to run position manually
2) Engine Throttle – Push up and down buttons
