Main Menus
Main Menus
Sub Menus
Emissions Parameters
Regen Options (Auto, Inhibit, Request)
DPF Soot Load % View
DPF Ash Load % View
Time Since Last Regen View
Regen Active/Not Active View
Regen Inhibited/Not Inhibited View
DPF Out Gas Temperature View
DPF Differential Pressure View
Active Engine Fault Codes
View/Scroll Active Fault Codes
Stored Engine Fault Codes
View/Scroll Stored Fault Codes
Operation Event Log
View Last 32 Events (Start, Stop, Alarms)
Alarms Event Log
View Last 32 ECU and Controller Alarms)
Engine Parameters
View ECU Engine Information
(% Load, Torque, Oil Temp, etc.)
Engine Identification
Engine Model # View
Engine Serial # View
Module Information
Control Unit Part# View
Control Unit Software Version View
Controller Setup
Input Configuration
(1)
(PASSWORD PROTECTED)
Output Configuration
(2)
Throttle Configuration
(3)
Engine Safety Configuration
(4)
Module Configuration
(5)
CAN Configuration
(6)
Emissions Configuration
(7)
Clutch Configuration
(8)
Viewing Menus
Configuration
Menus
