CONTROL PANEL OUTPUTS
The panel has two outputs available to signal other devices based on predefined events. These
Outputs can be used for a number of purposes including engine operation or driving an audible
alarm.
Input
Heading
Default
Connector
Pin
Output 1
B
1
Function
Fuel Run
Polarity
Positive
Initial State
On
Input
Heading
Default
Connector
Pin
Output 2
B
6
Function
Pre + Alarm Horn
Polarity
Positive
Initial State
On
Outputs are High Side with a 0.5A Maximum Draw
MENU SYSTEM
