CONTROL PANEL DIGITAL INPUTS
The panel has two digital inputs available to monitor other components, senders or signals. The
analog input is preset to fuel level and cannot be configured. The digital inputs can be used for a
number of purposes including alarms and shut downs.
Input
Heading
Default
Options
Connector
Pin
Digital 1
Normally
Open
Open / Closed
A
4
Function
None
Message
None
Check
Off
Off / Always / Run
Digital 4
Normally
Open
Open / Closed
B
3
Function
Throttle Up
Message
None
Check
Always
Off / Always / Run
Digital 5
Normally
Open
Open / Closed
B
4
Function
None
Message
None
Check
Off
Off / Always / Run
Digital 6
Normally
Open
Open / Closed
B
5
Function
Throttle Down
Message
None
Check
Always
Off / Always / Run
Digital 7
Normally
Open
Open / Closed
B
2
Function
Throttle Up
Message
None
Check
Always
Off / Always / Run
Digital Function
1) Pre Alarm – Warning message will be displayed along with a yellow lamp when active.
2) Throttle Up – Mimics the front panel key press for speed control.
3) Throttle Down - Mimics the front panel key press for speed control.
Digital Function Activation
1) Off / Always / Run – Describes when the parameter will be monitored for alarm conditions.
Run refers to when the engine is running. Off disables the alarm conditions. Always enables
the alarm constantly regardless of engine state.
2) Alarm Delay – The time period, after Sender Check Bypass, that the parameter must be on the
alarm condition before the alarm becomes latched.
