Controls MVP-L3100 - Module Connector Specifications

CONTROLS, INCORPORATED
C O N T R O L S Y S T E M S & S O L U T I O N S
4
MODULE CONNECTOR INFORMATION
BATTERY +
CAN HIGH
CAN LOW
SPEED INPUT
FUEL LEVEL INPUT
BATTERY -
BATTERY -
DIGITAL INPUT #1
FUEL HOLD
TEMP INPUT
OIL PRESS INPUT
OUTPUT #2
OUTPUT #3
1
2
3
4
5
6
1
2
3
4
5
6
