Convair CM9CW1 - Component Identification; Unit Parts and Diagram

OWNER’S MANUAL
|
3
Parts List
1. Control panel
2. Air deection vane control
3. Handles
4. Remote signal receiver
5. Enclosure
6. Upper air lter (behind grille)
7. Exhaust outlet
8. Castors
9. Evaporator air intake
10. Drain outlet plug
11. Condenser air intake
12. Lower air lter (behind grille)
13. Bottom tray drain outlet
14. Foam sealant
15. Window kit
16. Drain hose
17. Exhaust hose
18. Window kit screw
19. Hose end (unit side)
20. Hose end (window side)
21. Remote control
22. Rating Label
1
8
10
14
18
11
16
20
21
12
15
19
13
17
6
9
7
5
3
4
2
COMPONENT LOCATION
3
4
22
