6 Moving and setting up the appliance
ConvoVent 4 / ConvoVent 4+ 47
9.
Connect the ground cable to the spade terminal on the ventila-
tion port.
10.
For 6.10 and 6.20:
Re-tighten the left-hand rear screw on the top cover of the
appliance.
11.
Undo the two screws on the top cover of the appliance using a
Phillips screwdriver, then use the two screws to fit the fixing
bracket supplied.
12.
Break out the relevant perforation in the front cover depending
on what door is fitted.
Use a file to deburr the break-out points.
