COOK CA Series - Parts List: CPFB, CPA, CPS, CPV

11CA/CF/CP IO&M B51181-002
CPFB
Drive Side View Discharge Side View Inlet Side View
11
4
2
1
3
6
9
8
7
10 15
5
12
13 16
14
17
CPA, CPA-A, CPS, CPS-A CPV
1
2 3
4
5
6
Drive Side View Discharge Side View Inlet Side View
7
8
11
9
10 15
12
13
14
16
17
CPA, CPA-A, CPS, CPS-A, CPV with Original Curb Cap and Inlet Box Accessory
1
2
3
4
5
Side View Inlet Side View
Part No.
CPA, CPA-A, CPS, CPS-A, CPV with Optional Curb
Cap and Inlet Box Accessory Parts List
1 CP Vent Set
2 Adjustable Draw Latch
3 Access Door Assembly
4 Latch Keeper
5 Curb Cap/Plenum Box Assembly
6 Foam Tape (not shown)
Part No.
CPFB, CPA, CPA-A, CPS,
CPS-A, CPV Arr. 4
1 Motor Plate
2 Motor
3 Motor Sheave
4 Belt Set
5 Fan Sheave
6 Housing
7 Shaft
8 Outboard Bearing
9 Inboard Bearing
10 Wheel
11 Inlet Cone
12 Pedestal
13 Optional Side Cover (2)
14 Optional Weather Cover
15 Discharge Flange
16 Spreader Bar (2)
17 Inlet Side Support
