COOK CA Series - Parts List: CA,CF SWSI Arrangements

9CA/CF/CP IO&M B51181-002
Inlet Side View
12
5
6
4
3
2
1
Drive Side View
8
9
10
11
Discharge Side View
1
11
2
3
10
9
8
6
5
4
Drive Side View Discharge Side View Inlet Side View
12
6
12
11
Drive Side View Discharge Side View Inlet Side View
7
2
Part No. Arr. 10, CA-4 SWSI, CF-4 SWSI Arr. 4
1 Motor Plate -
2 Motor
3 Motor Sheave -
4 Belt Set -
5 Fan Sheave -
6 Housing
7 - Isolation Base (optional)
8 Shaft -
9 Outboard Bearing -
10 Inboard Bearing -
11 Wheel
12 Inlet Cone
CA, CF SWSI Arrangement 10
CA-4 SWSI, CF-4 SWSI
CA, CF SWSI Arrangement 4
5
4
3
2
1
Drive Side View
6
7
10
9
8
Discharge Side View
12
11
Inlet Side View
Discharge Side View
1
2
3
4
5
6
8
9
10
11
12
Drive Side View Discharge Side View Inlet Side View
Part No. Arr. 1 Arr. 3 Arr. 9
1 Motor Slide Base
2 Motor
3 Motor Sheave
4 Belt Set
5 Fan Sheave
6 Housing
7 Isolation Base (optional) -
8 Shaft
9 Outboard Bearing Drive Side Bearing Outboard Bearing
10 Inboard Bearing Free Side Bearing Inboard Bearing
11 Wheel
12 Inlet Cone
13 - Free Side Bearing Support -
14 - Drive Side Bearing Support -
Parts List
CA,CF SWSI Arrangement 1
CA, CF SWSI Arrangement 3
CA, CF SWSI Arrangement 9
