COOK GI - Page 3

3 B51116-002GI/GR IO&M
Hood Section
Section Rail
Section Rail Splice
Base Splice
Mounting Channel Splic
e
Mounting Channel
Support Angle
Filter retaining clip
Filter
End Panel
Base / Throat
Hood Panel
Mounting rail
Cross section of the end peice
Hinged bolt
Lifting lug
Cross section of the hood panel
Figure 3
Figure 4
