What to do if Cool Space Air Conditioner is spitting water?
If your Cool-Space unit is overflowing or spitting water, the float valve hose may be loose, the water pressure might be too high (exceeding 60psi), or the float valve isn't seating correctly. Try tightening the hose connections, replacing the hose washers, reducing water pressure with an inline reducer, and checking or replacing the float orifice.
Why does Cool Space Air Conditioner pump make loud noise while running?
If the pump makes a loud noise while running, it could be due to the pump bearings or an object in the impeller housing. Replace the pump or clear any object from the impeller housing.
Why does my Cool Space Air Conditioner breaker trip when the fan starts?
The breaker might trip or a fuse might blow when starting the fan because of a motor stall, or the power source might not be providing the minimum required 115v/20 amp. To address this, replace the motor, upgrade the power supply, or replace the extension cord with a heavier one.
Why does my Cool Space Air Conditioner motor overheat and shut off?
The motor may be overheating and shutting off due to an extension cord with too small a gauge, obstructed inlet air, or a faulty motor. Replace the extension cord with a heavier one, ensure at least 3’ of clearance for inlet air, and consider replacing the motor.
How to fix dry streaks in Cool Space Air Conditioner pads?
If you notice too many dry streaks in the pads, it could be due to blocked holes in the spray bar or incorrect water flow. You should remove the spray bar, remove the plug and clean the tube and holes, and open the water flow control valve.
Why Cool Space Air Conditioner fan will not reach full speed?
If the fan turns but doesn't reach full speed and makes a humming sound, check the capacitor and motor electrical connections, as well as the extension cord. Replacing the capacitor or motor, or increasing the cord gauge might solve the issue.
Why Cool Space Air Conditioner fan blade doesn't turn and makes squealing sound?
If the fan blade doesn’t turn and the unit makes a squealing sound, the start capacitor might be leaking, the motor might be stalled, the fan belt could be loose or broken, or the fan pulley might be spinning on the shaft. Replace the capacitor or motor, tighten or replace the fan belt, or tighten the pulley set screw.
Why Cool Space Air Conditioner fan motor won’t run and makes a humming sound?
If the fan motor won’t run but makes a humming sound, the blade might be in contact with the shroud or the motor might be stalled. Try re-centering the blade hub or replacing the motor.
Why Cool Space Air Conditioner pump motor hums but does not pump water?
If the pump motor hums when turned on but doesn't pump water, there might be an object jammed into the impeller blade or the pump motor might be locked. Remove any object and replace the pump.
Why is my Cool Space Air Conditioner drain valve leaking?
If water is leaking from the drain valve, the washer or stem might be worn, or the drain valve may not be completely closed. Replace the washer or the drain valve.
Connects the unit to a standard garden hose outlet for water supply. Specifies pressure limits and optional tank connection.
Details connecting the unit to a 120-volt, 20-amp, 60 Hz circuit, recommending GFCI protection.
Instructions on filling the unit's sump with water via the float valve to ensure proper operation.
Guide to starting the fan at HIGH speed and then setting to Medium or Low for optimal airflow.
Steps to turn on the pump and adjust water flow to cooling pads for efficient evaporative cooling.
Procedure for removing cooling pads to access internal components for maintenance and cleaning.
Daily shutdown procedure: turn off pump 15 mins before fan to drain and dry pads, preventing mildew.
Regular cleaning of the sump and pads to remove accumulated debris and impurities for optimal performance.
Instructions for cleaning and storing the unit during off-season, covering pad removal, sump draining, and protection.
Guidance on identifying and diagnosing problems by checking the unit's three main systems.
Detailed steps for replacing major components like fan motor and pump, with safety warnings.
Contact information for obtaining technical assistance and service from the manufacturer or distributor.
Information on filling out and returning the warranty registration form supplied with the unit.
Details on how to obtain replacement parts under warranty through distributors or direct contact.
Information on available optional accessories for the COOL-SPACE® unit, with ordering guidance.
Guidance on where to purchase replacement parts for the unit, through local distributors or suppliers.
General| Model | CS5-16 Series |
|---|---|
| Voltage | 220-240V |
| Refrigerant | R410A |
| Weight | 32 kg |
| Cooling Capacity | 16000 BTU/h |
| Power Supply | 50Hz |
| Power Consumption | 1500W |
