The extended I/O address does not require programming, is automatically
assigned, and the module is easy to use by plugging and playing.
◆
Digital input and output expansion, the expansion address starts from
X20, Y20.
◆
L02 series can be matched with L02-EIP module to establish remote
I/O communication.
Remarks: 256 points (X0~X177, Y0~Y177) in FX3G mode.
512 points (X0~X377, Y0~Y377) in FX3U mode.
3) Diversified I/O module option
◆
L02 series CPU modules support the following types of I/O modules:
digital I/O modules, analog I/O modules, temperature and weighing modules,
and Ethernet/IP modules.
Module Type
I/O
Model
Digital I/O
modules
Input
L02-8EX,L02-16EX,L02-32EX
Output
L02-8EYT,L02-8EYR,L02-16EYT,L02-
16EYR,L02-32EYT
Mixed
Input/Output
L02-16ET,L02-16ER,L02-32ET
Analog I/O
modules
Input
L02-4AD
Output
L02-4DA
Mixed
Input/Output
L02-4AD2DA
Temperature and Weighing modules
L02-4RTD,L02-4TC,L02-4NTC,L02-2TC
Ethernet/IP modules
L02-EIP
4) Larger program capacity and data memory block
◆L02 series CPU module, the program capacity can reach 32k steps.
Built-in 8K registers (128 points for usual, 7872 points for power failure
retention), and 24k file registers (support power failure retention).
5) Support Mitsubishi programming software
◆
L02 series CPU module, the programming software is compatible with
GX Developer8.86/GX Works2.
