Revised: 13/05/2021 10 of 13 Printed: 14/10/2021
Baffle plate removal
The baffle plate is held in place with four locating tabs – 2 either side, front and rear of the firebox.
WARNING: ALLOW THE HEATER TO COOL IF HOT BEFORE ATTEMPTING BAFFLE
DO NOT USE HEATER IF TOP BAFFLE IS DAMAGED
Steel Baffle – Installed from front of heater
The baffle plate should be removed and inspected annually and flaky deposits shaken or brushed off.
The most convenient time to maintain the baffle is when the flue is being cleaned.
DO NOT USE HEATER IF TOP BAFFLE IS DAMAGED
