APPLICATION GUIDE

Ancillary Devices

1. Detection

Standard devices include Photoelectric, Ionisation (which will be obsolete by Dec 2007), Multimode heat and the

replacement for the Ion, the OptoThermal.

The heat detector defaults to RoR when the panel is in Auto learn, these must be set to the required value RoR, BS

(ﬁxed 60 deg) or CS (ﬁxed 78 deg) before upload or download to the laptop.

The OptoThermal has both an optical smoke chamber and a heat element that work in tandem such that the smoke

half becomes more sensitive when heat is also present.

Each element will also work independently such that the heat is ﬁxed temp 60 deg and the optical has slightly

reduced sensitivity (but remains within the tolerances laid down by EN54).

The OptoThermal and heat detectors are capable of responding to Day/Night programming described on page 16

2. Callpoints

Callpoints are supplied as Surface, Flush mounted and IP 67 Weatherproof. Various accessories can be ﬁtted such

as the hinged protective cover, recessing bezel and resettable plastic element.

Generally the inputs of this device are used primarily for Fire, but the Input programming in Site Installer gives the

options of setting them to ﬁre, fault, reset, silence, pre-alarm and evacuate.

A call point can also be used to initiate day night mode, isolate addresses or zones or be set to non-latching.

3. Sounders

Sounders, beacons, sounder beacons all appear on the CF3000 / DF6000 / FX6000 device list as alarm/beacons and

a maximum of 60 are allowed per loop, the panel and site installer treats them all the same for programming purposes.

The site installer allows 3 stages for the device outputs and various options can be chosen at each stage. Delays

can ONLY be used on stage 1. (There is NO hierarchy on the stages whichever setting fulﬁls the requirement the

sounder/beacon will comply with that setting) The settings i.e. sound or volume for the sounders can be done

globally at the panel or individually on site installer.
