Analogue Level
The analogue level reading is used to display the analogue value being sensed by the detector, this value is displayed
in a numeric format and also in a graphical form. This reading is displayed in real time.
On v3.0 software Next/Previous buttons have been added to enable the user to scroll through the addresses more
easily. The min/max values are erased on exiting the menu and resetting the panel.
Printer Settings
When the printer is fitted then there are two options for its operation: Auto and On Request.
When changing between the two, the panel needs to have a hard reset or power down/power up to see the change in
the settings.
If the printer is replaced then a hard reset or power down should also be carried out to recognise the printer.
Programming I/O and Sounders & Sub-Menus
There is a number of sub – menus within this screen.
1. Panel Outputs
The only sounder programming which can be changed on the panel is the sounder tone and the volume, if these
settings are changed then the changes are applied to all the sounders on the system whereas if the settings are
done on the site installer software then it is possible to individually configure the sounder tone and volume for each
sounder.
These controls only apply to loop powered sounders.
There are 3 volume settings: Low, Medium, High;
and 4 tones: Pulsing, Continuous, Two Tone, Slow Whoop
The panel sounder circuits are limited in the way they can be programmed, the three stages available to the loop
sounders are not available for the panel sounders. They should really only be used when the system is a one out all
out configuration, if anything more complex is required then loop sounders are the best option. If conventional
sounders are required they need to be controlled by a sounder control unit.
The zone monitor unit is not included in the quantity of interface units allowed per loop.
The shop unit interface is not included in the quantity of interface units allowed per loop and always requires a
power supply unit. If no power supply is connected then the shop unit interface will show a fault, as it is unable to
monitor the sounder circuits.
