KEY-KP01
Keep the prox reader cable clear of cables supplying sounders or extension
loudspeakers.
External Prox Reader Connection
Figure 11 shows the wiring connections at the keypad. Do not connect the yel-
low wire.
Maintenance
The only maintenance required is an annual test of the keypad keys and clean-
ing.
Testing the Keys
To start testing, make sure the system is idle then:
1. Enter the Installer Menu and select Test.
The display shows the Test menu.
2. Select Keypads.
3. Press each key once. The display shows a character in response. Press both
HUA keys together to test. Press X to end the test.
Cleaning
Clean the outside of the case with a soft dry cloth. Do not use water, solvents
or any proprietary cleaning agents.
Programming
Backlight, ABCD LEDs and Navigation Key LEDs
When connecting the keypad to an i-on16 or i-on40 you can enable or disable
the backlights, set the function of the LEDs on the ABCD keys or disable/enable
the LEDs under the navigation key by entering a local keypad programming
mode (this replaces the use of jumpers on the keypad PCB). i-onEX and Men-
vier30/40/100/300 control units can change the keypad backlighting from the
installer Menu - do not use the keypad’s local programming mode.
It is possible to enter keypad programming mode when the keypad is not con-
nected to a control unit, but simply powered by 12Vdc connected to the keypad
bus terminal (see Figure 7). If the keypad IS connected to a control unit then
make sure that the control unit is in Installer Menu before entering the key-
pad’s local programming mode.
Entering Local Programming Mode
Action Keypad Display
1. Apply 12Vdc to the keypad.
2. Enter Installer Menu on the control unit, if the
keypad is connected to a system.
3. Open the keypad tamper.
4. Press and hold down B and Y together for at
least two seconds.
The keypad is now in local programming mode,
the display shows the current status.
MENU
ABCD Y
To Next Page
