Page 5
KEY-KP01
Fig. 10.
Fig. 11.
12V 0V D0 D1 LED
EXT READER
BLUE (LED)
WHITE (D1)
GREEN (D0)
BLACK (0V)
RED (12V)
External
Prox
Reader
KEY-KP01
Note: Do not connect
yellow wire.
