McGraw-Edison VR-32 Regulator and CL-5 Series Control
1-5
TABLE 1-1
Setting the Controls for Basic Operation
Security System
Keys to Depress F.C Display Description
FUNCTION, 99, ENTER 99 _ _ _ _ _
12121, ENTER Func _ _ The security system is now activated for changing operational settings
Set Voltage
Range: 100.0 - 135.0 (Factory Setting: 120.0)
Keys to Depress F.C Display Description
1 01 120.0 This is the set voltage as shipped from the factory
Change 01 _ _ _._c Enter the desired value. Example: 122.0
1220, ENTER 01 122.0 The set voltage is now 122.0 volts.
Bandwith
Range: 1.0 - 6.0 (Factory Setting: 2.0)
Keys to Depress F.C. Display Description
2 02 2.0 This is the bandwith as shipped from the factory
Change 02 _._c Enter the desired value. Example: 3.0
30, ENTER 02 3.0 The bandwidth is now 3.0 volts
Time Delay
Range: 5 - 180 (Factory Setting: 30)
Keys to Depress F.C. Display Description
3 03 30 This is the time delay as shipped from the factory
Change 03 _ _ _c Enter the desired value. Example: 45
45, ENTER 03 45 The time delay is now 45 seconds
Line Drop Compensation, Resistance
Range: -96.0 - +96.0 (Factory Setting: 0.0)
Keys to Depress F.C. Display Description
4 04 0.0 This is the resistive compensation as shipped from the factory
Change 04 _ _._c Enter the desired value. Example: 5.0
50, ENTER 04 5.0 The resistive compensation is now 5.0 volts
Line Drop Compensation, Reactance
Range: -96.0 - +96.0 (Factory Setting: 0.0)
Keys to Depress F.C. Display Description
5 05 0.0 This is the reactive compensation as shipped from the factory
Change 05 _ _._c Enter the desired value. Example: 3.0
30, ENTER 05 3.0 The reactive compensation is now 3.0 volts
Regulator Configuration
Range: 0 - 2 (Factory Setting: 0 [Wye or Star])
Keys to Depress F.C. Display Description
FUNCTION, 41, ENTER 41 0 This is the regulator configuration as shipped from the factory
Change 41 _c Enter the desired value. Example: 1
1, ENTER 41 1 The regulator configuration is now Delta Lag
Control Operating Modes
Range: 0 - 2 (Factory Setting: 0 [Sequential])
Keys to Depress F.C. Display Description
FUNCTION, 42, ENTER 42 0 This is the control operating mode as shipped from the factory
Change 42 _c Enter the desired value. Example: 1
1, ENTER 42 1 The control operating mode is now Time Integrating
System Line Voltage
Range: 1200 - 36000 (Factory Setting: Regulator Rated Voltage)
Keys to Depress F.C. Display Description
FUNCTION, 43, ENTER 43 7620 This is the system line voltage for a 7620 volt regulator as shipped from the factory
Change 43 _ _ _ _ _c Enter the desired value. Example: 7200
7200, ENTER 43 1 The system line voltage is now 7200 volts
Overall Potential Transformer Ratio
Range: 10 - 300 (Factory Setting: PT ratio for Regulator Rated Voltage)
Keys to Depress F.C. Display Description
FUNCTION, 44, ENTER 44 63.5 This is the overall PT ratio for a 7620 volt regulator as shipped from the factory
Change 44 _ _ _._c Enter the desired value. Example: 60.0
600, ENTER 44 60.0 The system line voltage is now 7200 volts
Calendar Clock
Range: 10 - 300 (Factory Default Setting XX)
Keys to Depress F.C. Display Description
FUNCTION, 50, ENTER 50 1.01 This is the default value for the date.
Scroll up 50 x
.xx This is the present time (hour/minute).
Scroll up 50 1d 90 This is the default value for the year, 1990.
Change 50 1 _ _c Enter the desired value for Year. Example: 2000
00, ENTER 50 1 0 The Year is now 2000.
Scroll up 50 2 1 This is the default value for the month, January.
Change 50 2 _ _c Enter the desired value for Month. Example: October
10, ENTER 50 2 10 The month is now October.
Scroll up 50 3 1 This is the default value for the Day 1.
Change 50 3 _ _c Enter the desired value for the Day. Example 24.
24, ENTER 50 3 24 The Day is now 24.
Scroll up 50 4 xx This is the present value for the Hour, xx.
Change 50 4 _ _c Enter the desired value for Hour. Example: 2:00 P.M.
14, ENTER 50 4 14 The Hour is now 14. Military Time.
Scroll up 50 5 xx This is the present value for the Minutes. Example: xx.
Change 50 5 _ _c Enter the desired value for Minutes. Example: 30.
30, ENTER 50 5 30 The Minutes is now 30.
Scroll up 50 6 xx This is the present value for the Seconds, xx.
Change 50 6 _ _c Enter the desired value for Seconds. Example 45.
45, ENTER 50 6 45 The Seconds is now 45.
